Project has been registered with TDLR and is in pre-construction phase
16 HANDLES AUSTIN is a Alteration/Renovation project located at 8300 NORTH FM 620 SUITE L-500 in Austin, Texas. The project has an estimated value of $80K covering 2,180 sq ft. JAMES DUFFY is the property owner. The project was registered with TDLR on May 21, 2025.
PROJECT SCOPE CONSISTS OF TENANT BUILDOUT OF AN EXISTING EMPTY SHELL COMMERCIAL SPACE INTO A 2,180 SF FROZEN YOGURT/ ICE CREAM SHOP.
Note: This project is registered under the Texas Accessibility Standards (TAS) program. TDLR registration is required for commercial and public facility construction to ensure compliance with accessibility requirements under Texas Government Code Chapter 469.
Filed
May 20, 2025
Review Complete
Inspection Complete
Closed
