ELGIN PROVIDENCE FUNERAL HOME

This permit will cover: Bathroom circuits Living room receptacles Bathroom Circuits Recently purchased older residence; existing bathroom has no receptacle outlets. Bathroom walls have original tile the homeowner wants to preserve. Receptacles will be surface mounted inside the cabinets flanking the sink to avoid cutting into the tile meeting the 3 ft basin-proximity requirement. Adds 2 new 20A 120V GFCI breaker-protected circuits for bathroom receptacles run through a 1 EMT raceway from the exterior main panel to an accessible attic J-box allowing easier future circuit additions. This raceway also carries the living room circuit below. Installation: Install 1 raceway from panel to a centrally located 8x8x6 J-box in accessible attic space. From there pipe to a 4-square J-box above the bathroom then into the upper cabinets on either side of the sink. Install surface-mount quad receptacles with industrial covers inside the cabinets. Living Room Receptacles Adds a 20A 120V AFCI-protected circuit for in-wall receptacles in the living room located behind a future bookshelf. Shares the 1 EMT raceway from panel to the 8x8x6 J-box branching separately from that point. Installation: From the 8x8x6 J-box pipe to a new 4-square box above the bookshelf location then down to the receptacle locations. Wire size: All three circuits supplied with #10 THWN-2 sized for high attic temperatures and conductor-count adjustments. All raceways installed per code; terminations torqued per manufacturer specifications.

Install Driskill Grill illuminated wall sign.

Install (N) 10 kWh ESS on (E) 2.61 kWDC PV System.

Replacement of complete existing central heat and air system with or without duct work

we will be adding a 60amp 240v 3wire 2-#6 awg with 1-#10 awg ground on a 60 amp breaker. we will be routing this from the exterior panel and poking into the home between the subfloor of the second story and the ceiling of the first story. this installation is for an EV charger located approx. 80 from the homes exterior panel.
