Final inspection completed, awaiting project closure
CALLAWAY GOLF is a Alteration/Renovation project located at 8300 N.MOPAC EXPRESSWAY, SUITE 125 in Austin, Texas. The project has an estimated value of $400K covering 9,134 sq ft. OP 8300 MOPAC PROPERTY LLC C/O LUKE PHILLIPS is the property owner and Red Design Studios is the design firm of record. The project was registered with TDLR on May 27, 2025.
This project consists of the demolition and finish out of an NEWLY demised tenant suite. Suite occupancy classification and use group remains unchanged by the scope of this work.
Note: This project is registered under the Texas Accessibility Standards (TAS) program. TDLR registration is required for commercial and public facility construction to ensure compliance with accessibility requirements under Texas Government Code Chapter 469.
Filed
May 27, 2025
Review Complete
Inspection Complete
May 27, 2025
Closed
