Design review complete, construction may proceed
UT Patton Fire Lane Repaving is a Renovation/Alteration project located at 305 E 23rd Street, Austin, TX 78712 in Austin, Texas. The project has an estimated value of $250K covering 10,890 sq ft. University of Texas at Austin is the property owner and Walter P Moore is the design firm of record. The project was registered with TDLR on July 25, 2025.
Reconstruction of an existing fire lane and adjacent parking spaces. Approximate limits of work are 0.25 acres.
Note: This project is registered under the Texas Accessibility Standards (TAS) program. TDLR registration is required for commercial and public facility construction to ensure compliance with accessibility requirements under Texas Government Code Chapter 469.
Filed
Jul 25, 2025
Review Complete
Jul 25, 2025
Inspection Complete
Closed
Building permits found at or near this location
Construct new driveway approach of 28 FT and sidewalk of 11FT 6IN with curb/gutter of 91.2ft
We will be adding mulitple panels and receptacles for tenant to put in equipment and office area. There will be no additional meter needed. 40 20A 120V. DUPLEX RECEPTACLE 7 - 20A 120V. QUADRAPLEX RECEPTACLE These 120V outlets being installed are standard NEMA 5-20 (20A 125V duplex outlets). Each will have an FLA of 10A and will be wired with #12 CU stranded wire. There are also: (5) 125A 480V equipment feeds with a safety disconnect and #1 CU wire (3) 70A 480V equipment feeds with a safety disconnect and #4 CU wire (3) 30A 208V equipment feeds with a safety disconnect and #10 CU wire
Replacement of mini-split system
Install new transformer and 400A sub panel Ok Per Steve Leitch. Reference 2025 146628 DA (Wiring to storage and employee restroom receptacles for cameras all on site plan. guard shack?)
interior remodel - see attached document
